CHOOSE MOLITRON FOR YOUR COMMERCIAL ODOR CONTROL
Environmentally Sound
This solution does not produce any waste byproducts. It accomplishes this by dispensing a neutralizing solution via two misting nozzles installed in the exhaust airstream. This technique reduces smoke and odor without using any filter media.
Odor Control Misting System
Our systems produce a fine mist that chemically neutralizes the odor particle's molecular structure. Unlike fragrances or perfumes that superimpose a pleasant fragrance on an unpleasant odor, our neutralizing solution absorbs and converts malodors which reduces odor and smoke particles by up to 50%!
Environmentally Sound
This commercial system does not produce any waste byproducts. It accomplishes this by dispensing a neutralizing solution via two misting nozzles installed in the exhaust airstream. This technique reduces smoke and odor without using any filter media.
Odor Control Misting System
Our commercial odor control systems produce a fine mist that chemically neutralizes the odor particle's molecular structure. Unlike fragrances or perfumes that superimpose a pleasant fragrance on an unpleasant odor, our neutralizing solution absorbs and converts malodors which reduces odor and smoke particles by up to 50%!
Small Footprint
The Molitron Odor Abatement System has a relatively small size of 2ft x 3ft and allows it to be conveniently located on a wall inside the building. This commercial odor control system provides a low cost and noninvasive solution for new businesses or current ones that are looking to increase the efficiency of their existing emissions control unit.
Self-Contained Systems
All necessary components, except for the remote atomizing nozzles, are located in a stainless steel wall-mounted cabinet. Utilities required are one 115 VAC circuit and a 1/4” cold water supply. Connecting the MOAS cabinet to the remote atomizing nozzles is one 1/4” OD liquid tube and one 3/8” OD air tube.
Play Video
Self-Contained
All necessary components, except for the remote atomizing nozzles, are located in a stainless steel wall-mounted cabinet. Utilities required are one 115 VAC circuit and a 1/4” cold water supply. Connecting the MOAS cabinet to the remote atomizing nozzles is one 1/4” OD liquid tube and one 3/8” OD air tube.
Small Footprint
The Molitron Odor Abatement System has a relatively small size of 2ft x 3ft and allows it to be conveniently located on a wall inside the building. This commercial odor control system provides a low cost and noninvasive solution for new businesses or current ones that are looking to increase the efficiency of their existing emissions control unit.
Odor Abatement Systems
0
Installed
Across the USA and Canada
MOLITRON ODOR CONTROL SYSTEMS
Our systems include an exhaust fan interlock which ensures the misting nozzles spray, only when the exhaust fan is turned on.
The business will need to supply:
- One 115 VAC circuit
- One 1/4” cold water supply
Dimensions:
Height: 32″
Width: 24″
Depth: 8″
Weight: 100lbs
10 Gallon commercial odor control solution container which can be easily refilled when the low odor solution alarm sounds.
All our systems are furnished with two misting nozzle assemblies which are adequate for up to 6,000 CFM. (See Above Video)
Low odor control solution alarm for alerting staff to refill the odor neutralizing solution. Red light illuminates and buzzer sounds, when the solution is low.
Delivers compressed air to the odor control misting systems.
Provides odor system control and setting user defined system running periods.
Solution pump for delivering the odor neutralizing solution to the odor control misting systems.
Delivers the water and concentrated odor neutralizer to the mixing container. Satisfactory odor control solution performance can be increased or decreased by adjusting the injector dilution ratio.
Stores the water and the concentrated odor neutralizer mixture for pumping to the misting nozzles.
MOLITRON POLLUTION CONTROL UNIT
(ENVIRO-PAK FILTER ASSEMBLY)
Designed for Any Ventilation Hood
Our systems are purpose-built for a multitude of exhaust emissions. Whether you are a commercial kitchen nestled into a dual-purpose property, or maintaining a cannabis greenhouse the Molitron Enviro-Pak Filter Assembly can be installed inside or outside the business, between the ventilation hood, and the point of discharge from the exhaust air into the atmosphere.
Commercial Odor Control
The Enviro-Pak Filter Assembly (EPFA) is an 18-gauge, type 304 stainless steel enclosure fitted with top, bottom and end channels for holding in place pre-filters, optional carbon filters, and high efficiency filters used for removing cooking emissions and grease exhaust from the air stream.
8782 Compliant
UL 8782 covers Pollution Control Units for commercial cooking. Emissions control equipment (PCU) are part of the restaurant kitchen exhaust system and are designed to control effluent and smoke from the commercial cooking process. See UL 8782 for more information.
Activated Carbon Filter Option
Businesses that require a higher degree of odor compliance due to especially pungent air, may want to invest in our activated carbon filters. Adding this additional layer of odor mitigation to the 3rd row in our commercial odor control systems, will further reduce even the most potent odor from the air stream.
Commercial Odor Control
The Enviro-Pak Filter Assembly (EPFA) is an 18-gauge, type 304 stainless steel enclosure fitted with top, bottom and end channels for holding in place pre-filters, optional carbon filters, and high efficiency filters used for removing cooking emissions and grease exhaust from the air stream.
Designed For Any Ventilation Hood
Our systems are purpose-built for a multitude of exhaust emissions. Whether you are a commercial kitchen nestled into a dual-purpose property, or maintaining a cannabis greenhouse the Molitron Enviro-Pak Filter Assembly can be installed inside or outside the business, between the ventilation hood, and the point of discharge from the exhaust air into the atmosphere.
Activated Carbon Filter Option
Businesses that require a higher degree of odor compliance due to especially pungent air, may want to invest in our activated carbon filters. Adding this additional layer of odor mitigation to the 3rd row in our commercial odor control systems, will further reduce even the most potent odor from the air stream.
8782 Compliant
UL 8782 covers Commercial Odor Control for commercial cooking. Commercial Systems are part of the restaurant kitchen exhaust system and are designed to control effluent and smoke from the commercial cooking process. See UL 8782 for more information.
Recent Installations
Previous slide
Next slide
Our Enviro-Pack Filter Assemblies are commercial odor control systems designed to not only reduce commercial kitchen smoke, grease and particulate matter but also very effective at minimizing other sources of emissions such as exhaust from cannabis greenhouses.
Our systems have three removable doors in order to replace the high efficiency air filters and/or carbon filter.
Our systems are ANSUL pre-piped to integrate with the building’s fire suppression setup.
All of our commercial odor control systems are designed to accommodate your business’s need for a left or right-side inlet/outlet access based on the direction of the airflow. Additionally, these systems can be scaled and/or stacked to meet your CFM and footprint requirements.
Length: 63 inches
Height: 26 inches
Width: 2 -12 feet per CFM requirements.
This monitor is put into place inside your business to monitor the health of the high efficiency filters and notifying when they should be replaced.
Our MERV 14 rated high efficiency filters reduce up to 95% of smog, odor and grease vapors from the exhaust air flow.
For odors that are more pungent and require a higher degree of odor mitigation, our activated carbon filter can be installed in the third row of the EPFA.
Our pre-filters are the first line of defense to reduce larger particles in the airstream, thus extending the life of the high efficiency air filters that do most of the work.
